What is a Piso WiFi vendo machine?
A Piso WiFi vending machine is a coin-operated box that sells timed internet sessions over WiFi. A locked cabinet holds a coin acceptor and a control board running Piso WiFi firmware, while an access point broadcasts the signal.On TP-Link’s example rate card, ₱1 buys 10 minutes and ₱5 buys one hour.
“Vendo” is the Filipino word for vending machine, and “piso” means peso, so many owners just call it a piso vendo. The operator brings in the line from an internet provider through a router. Each customer then buys pay-per-use internet through a captive portal that opens on their phone.
How does a Piso WiFi vendo work?
A Piso WiFi vendo works by turning coins into internet time. The coin acceptor sends a pulse to the control board, which adds minutes to the phone’s MAC address. When the session timer hits zero, the session expires and the captive portal blocks the device until it pays again.
Here is how to use Piso WiFi vendo machine time as a customer.
- Connect to the vendo’s WiFi name (SSID).
- Wait for the portal page to open.
- Tap Insert Coin, or enter a voucher code.
- Drop your coins before the countdown ends, then tap Start.
Knowing how Piso WiFi vendo works helps owners trace a complaint to the step that failed, such as a coin that never sent its pulse. Remaining time, pause and resume all sit on the same portal page.
What payment methods does a Piso WiFi machine accept?
A Piso WiFi machine accepts ₱1, ₱5 and ₱10 coins through a multi-coin acceptor, which sends a different pulse count for each coin. Most systems also sell voucher codes, and LPB includes e-payments through GCash and Maya in both of its licenses.
A sub vendo is a second coin box linked to the main machine, so customers on another floor can pay nearby. AdoPiSoft also sells a wireless sub-vendo kit, so the second box doesn’t need a long cable run.
How is vendo WiFi different from regular WiFi?
Vendo WiFi is different from regular WiFi because each customer pays for a timed session instead of sharing one home WiFi password. Home WiFi gives unlimited use to anyone who knows the password. A vendo turns that into controlled public access, where the captive portal lets each device go online only for the time it bought.
Customers need no subscription, SIM registration or personal details, so anyone nearby can pay and connect. PisoNet is the older version of the same idea, renting coin-operated computers by the minute instead of selling WiFi time to phones.
How much is a Piso WiFi vendo machine in the Philippines?
A Piso WiFi vendo machine in the Philippines costs about ₱6,000 to ₱9,000 as a DIY starter kit and ₱15,000 to ₱30,000 as a plug-and-play unit. Those are the 2026 ranges in TP-Link Philippines’ operator guide. Some low-priced listings are the box only, so confirm the board, coin acceptor, access point and license are included.
Piso WiFi price list (2026)
| Setup type | Typical price | What you get |
|---|---|---|
| DIY starter kit | ₱6,000 to ₱9,000 | Board or router, coin acceptor and software license, usually without the box |
| Plug-and-play vendo | ₱15,000 to ₱30,000 | Assembled cabinet, wired and ready to plug in |
| Box only | Cheapest listings | Empty casing with no electronics |
AdoPiSoft’s DIY kit with an Orange Pi PC, a TP-Link EAP110-Outdoor and two license keys is listed at ₱6,647, without the box. In 2016, a basic unit cost around ₱25,000, so entry prices have fallen sharply.
The piso wifi vendo machine price is only part of the deal when you compare Piso WiFi price Philippines listings. The license fee and warranty decide what you actually get. Ask the seller to register the license to your own account before you pay the balance.
What does a Piso WiFi vendo price include?
A Piso WiFi vendo price should include the control board or router, coin acceptor, access point, software license, power supply, cables and a warranty. The internet line is not part of the price, because you pay your ISP for it separately. Installation and configuration are sometimes extra.
A complete piso wifi vendo package spells these out in a written parts list. Send this checklist to the seller before you order.
- Models: the exact board, access point and antenna.
- License: the software name and how long it lasts.
- Enclosure: whether a cage or box comes with it.
- Setup: whether installation and configuration are included.
- Warranty: how many months, and whether it covers parts only.
Is a DIY Piso WiFi kit cheaper than a ready-made vendo?
A DIY Piso WiFi kit is cheaper than a ready-made vendo because you assemble it and supply your own box. AdoPiSoft’s ₱6,647 kit costs over ₱8,000 less than an entry-level ₱15,000 plug-and-play unit. The trade-off is your time and some basic wiring skill.
A kit piso wifi bundle such as AdoPiSoft’s covers the board, microSD card, coin acceptor, power adapter, access point and license key.. Kits also include a relay or custom board that switches the coinslot on. Learning how to make Piso WiFi vendo machine builds comes down to four jobs: flash the SD card, wire the coin acceptor, connect the access point and mount it all in a box.
| Option | Best for | Cost | Skill needed | Support |
|---|---|---|---|---|
| Ready-made vendo | Owners who want it running today | Highest | None | One seller for the whole unit |
| Piso WiFi DIY kit | Owners comfortable with basic wiring | Middle | Basic wiring and flashing | One seller for the kit |
| Individual parts | Builders who already own some parts | Varies | Wiring, flashing and troubleshooting | A different seller for each part |
Where can you buy a Piso WiFi vendo machine?
In the Philippines, you can buy a Piso WiFi vendo machine from an official software distributor, a local installer, or online on Shopee, Lazada and Facebook Marketplace. The safest seller gives a written parts list, a license registered to your account and a warranty. LPB lists 21 distributors on its official purchase page.
Knowing where to buy Piso WiFi vendo machine units comes down to how much help you need after the sale. A local Piso WiFi supplier can mount the unit and come back when something breaks. Online piso wifi vendo machine for sale listings give more choice, and AdoPiSoft sells kits through its own online shop. Carousell and Facebook groups also list second-hand units.
What is the best Piso WiFi vendo to buy?
The best Piso WiFi vendo machine to buy has an outdoor access point, a multi-coin acceptor, a locked steel cage and a license in your name. It should also come with at least a one-year warranty. Brand matters less than these specs.
| Spec | What to look for | Why it matters |
|---|---|---|
| WiFi band | Dual-band 2.4 GHz and 5 GHz | 2.4 GHz reaches farther, and 5 GHz is faster up close |
| Access point | Outdoor-rated, with range that covers your area | Customers outside the signal can’t pay |
| Simultaneous users | Fits your busiest hour | Too few slots turns paying customers away |
| Coin acceptor | Multi-coin, from a known brand | Cheap slots jam and reject good coins |
| Cage | Steel with a key lock | It protects the coins and the board |
| License | Registered to your own account | You keep it if you change sellers |
| Warranty | At least one year | It covers early board or adapter failures |
Listings that say “Piso WiFi vendo 5G” usually mean the 5 GHz WiFi band, not 5G mobile data. Piso WiFi specs tell only half the story, so read owner reviews in Facebook groups and on Reddit before you buy.
What should you check before buying a second-hand Piso WiFi vendo?
Before buying a second-hand Piso WiFi vendo, confirm the license is active and can move to your account, and get the admin password. On LPB, Machine Transfer moves a machine between distributor accounts with two-step email verification, so arrange the transfer through the distributor before you pay.
Test the coin acceptor with ₱1, ₱5 and ₱10 coins to spot a worn slot. Boot the machine to check that the board and SD card load the portal. If the seller reflashed the card, confirm the license still shows. Ask for receipts, and check that the access point matches the listing.
What are the parts of a Piso WiFi vendo?
The parts of a Piso WiFi vendo machine are a control board, a microSD card, a coin acceptor, a relay, a power supply, an access point and a lockable cage. Most parts of Piso WiFi vendo machine builds are sold on their own, so you can replace one failed piece without buying a new machine.
| Part | What it does | Example |
|---|---|---|
| Piso WiFi board | Runs the firmware and tracks sessions | Orange Pi One or PC, Raspberry Pi 3, 4 or 5, Newifi 3 D-2 |
| microSD card | Stores the firmware and settings | 16GB card |
| Coin acceptor | Reads coins and sends pulses | Allan, universal or programmable multi-coin coinslot |
| Relay module | Turns the coin acceptor on when a customer taps Insert Coin | 5V relay |
| Buck converter | Powers the board and coinslot from one supply | HW-688 |
| Power supply | Feeds the whole machine | 12V 5A adapter |
| Access point | Broadcasts WiFi to customers | TP-Link EAP110-Outdoor |
| Cables and adapter | Link the ISP modem or router to the board and access point | Cat6 cable, USB-to-LAN adapter for single-port boards |
| Enclosure | Locks and protects everything | Steel vendo cage |
Orange Pi boards are the cheapest option among piso wifi vendo parts, which is why the DIY kits from AdoPiSoft and Circuitrocks both use them.
Which TP-Link router or access point works for Piso WiFi?
The TP-Link models recommended for Piso WiFi are the Omada EAP110-Outdoor access point, the dual-band EAP225-Outdoor for busier sites, and the TL-MR6400 router. TP-Link cites 50 to 100 meters of range for the EAP110-Outdoor at terminals. For sites without fiber, the TL-MR6400 Piso WiFi router takes a 4G LTE SIM.
A basic TP-Link Piso WiFi setup pairs the board with one outdoor Piso WiFi access point. The EAP110-Outdoor runs on 24V passive PoE through the injector in its box, so one cable carries data and power. Standard PoE switches like the LS105LP can’t power it, but they do power the EAP225-Outdoor, which supports 802.3af/at.
For Piso WiFi outdoor coverage, the EAP110-Outdoor ships with two detachable 3 dBi antennas that you can swap for higher-gain ones. Owners running several access points manage them from the Omada controller and separate them with VLAN.
How many users can one Piso WiFi vendo handle?
One vendo handles about 20 to 30 users at once on a 50 Mbps fiber line, based on TP-Link’s operator guide. For 50 or more users, TP-Link pairs an EAP225-Outdoor with a 100 Mbps plan. Your internet speed and per-user limit set the real cap, not the coin box.
A 50 Mbps plan split across 25 users gives each about 2 Mbps of bandwidth, which is enough for browsing and chat but tight for video. The access point is rarely the limit, because TP-Link rates the EAP110-Outdoor for 100+ simultaneous users.
Your license matters too. LPB Lite supports up to 50 users at once, excluding offline devices, while LPB Premium has no user limit.
How many watts does a Piso WiFi machine use?
A Piso WiFi machine uses little power, because its board, access point and coin acceptor are all low-power parts. TP-Link lists the EAP110-Outdoor access point at a maximum of 3.12 W. DIY kits run the whole machine from one 12V adapter rated 3A to 5A, so total piso wifi wattage stays under that adapter’s 36 to 60 W ceiling.
To work out your piso wifi vendo electricity consumption, add the watts on each part, multiply by 24 hours and 30 days, then divide by 1,000 for kWh. For example, a 25 W setup uses 18 kWh a month, which is about ₱271 at Meralco’s October 2026 typical household rate of ₱15.06 per kWh.
Brownouts are the bigger risk, because TP-Link notes that session timers reset on reboot and lead to refund disputes. It recommends a UPS with at least 15 to 30 minutes of backup, and an AVR or surge protector shields the board from voltage spikes.
What size Piso WiFi box or cage do you need?
The right Piso WiFi box size depends on what goes inside, because no standard size exists. A single-coinslot box only needs to hold the board, power supply, coin acceptor and coin bank, since an outdoor access point like the EAP110-Outdoor mounts outside. AdoPiSoft sells a ready vendo box for ₱1,699 with a camlock and key.
| Part | Where it goes | Room to plan for |
|---|---|---|
| Board | Inside, on a raised mount | About 85 × 55 mm for an Orange Pi PC, plus cable space |
| Power supply and HW-688 converter | Inside, away from the coins | Room for the adapter and airflow around it |
| Coin acceptor | Front panel | A cutout that matches your coinslot model |
| Coin bank | Bottom of the box | A bigger bank means fewer trips to empty it |
| Access point | Outside, on a wall or pole | Nothing inside the box |
A steel Piso WiFi cage resists prying better than a laminated wooden box, so it suits terminals and other open spots. To get the right piso wifi box size, lay your parts out, measure them with cables attached, and have a local fabricator build the cage around them. Mount it at eye level under a rain shelter, with vents near the top.
What is the best Piso WiFi software?
The best Piso WiFi software depends on your setup, and for most new owners we recommend starting with LPB Piso WiFi. It runs on cheap Orange Pi boards, and its Lite license costs ₱250 a year on promo. AdoPiSoft suits owners who want a free trial first, and JuanFi suits MikroTik users who want free, open-source code.
Piso WiFi software list (2026)
| Software | Piso WiFi license cost | Best for | Hardware | Notable features |
|---|---|---|---|---|
| LPB Piso WiFi | Lite ₱250, Premium ₱500 a year on promo (₱400 and ₱700 regular) | First-time owners | Orange Pi, Raspberry Pi, Newifi, PC | Remote Monitoring, GCash and Maya, Eload & Cash-in |
| AdoPiSoft | Lite \$16.99, Business \$65.99 (first year included) | Trying before buying | Orange Pi, Raspberry Pi, Newifi, x64 PC | Free trial, separate E-loading license key |
| JuanFi | Free and open source | MikroTik users | MikroTik hotspot router | Source code on GitHub |
Piso WiFi software is the firmware image you flash to the SD card, and it runs the captive portal and admin dashboard. Each machine needs its own license key. Wifi5soft and PisoFi also show up in seller listings, so check their license terms before you buy.
Can a Piso WiFi vendo do e-loading?
A Piso WiFi vendo can do e-loading when its software includes it, so customers buy prepaid mobile load with coins. LPB includes Eload & Cash-in in both of its licenses, while AdoPiSoft sells a separate E-loading license key. That turns the vendo into a small load station.
Eloading runs from a wallet the owner keeps topped up. LPB’s LPBSoft App handles wallet cash-in, including through QR Ph, and sells load for all major networks such as Smart and Globe. A piso wifi eload vendo also brings in customers who don’t need WiFi at all.
What internet connection does a Piso WiFi vendo need?
A Piso WiFi vendo needs a steady fiber line from PLDT, Globe Fiber or Converge for most sites. TP-Link names these three as the first choice for operators. Where fiber can’t reach, a 4G LTE SIM router such as the TP-Link TL-MR6400 works as the main line or as a backup line.
Fiber piso wifi setups hold their speed and latency better at peak hours, when mobile data slows down. On a PLDT Piso WiFi line, the fiber modem acts as your Piso WiFi modem and plugs into the board’s WAN port. TP-Link warns against smartphone hotspots because of throttling and daily caps.
Size the plan for your busiest hour, and check the upload speed too, because customers send photos and make video calls. Ask your ISP whether your plan allows business sharing before you open. Remote sites with no fiber or LTE coverage can use fixed wireless or satellite internet such as Starlink.
Where is the best place to put a Piso WiFi vendo?
The best place to put a Piso WiFi vendo is where people already wait or stay a while, because dwell time drives coin sales. Good spots include a sari-sari store, boarding house or dorm, jeepney or tricycle terminal, palengke, school gate or barangay hall. The spot also needs a safe power outlet, good signal and few rival machines nearby.
| Spot | Why it works | What to plan for |
|---|---|---|
| Sari-sari store | Steady foot traffic and an owner nearby | A revenue share with the store owner |
| Boarding house or dorm | The same tenants pay every night | Coverage that reaches every room |
| Jeepney, tricycle or bus terminal | Long waits and phones in every hand | An outdoor access point and a theft-proof cage |
| Palengke | Vendors and shoppers stay for hours | A UPS or a dedicated circuit, as TP-Link suggests |
| School gate or canteen | Students between classes | At least 50 connections, as TP-Link suggests |
| Residential compound | Homes without their own fiber line | Coverage across several houses |
In our experience, boarding houses bring the steadiest daily sales, because regulars pay every night. Before mounting, walk the area with your phone to test the signal and scan for other Piso WiFi names. If the spot belongs to someone else, put the revenue share in writing.
How do you install and set up a Piso WiFi vendo machine?
You install and set up a Piso WiFi vendo machine in three stages: flash the firmware, connect the cables and configure the admin panel. The firmware goes on a microSD card, the internet into the WAN port and the access point into the LAN port. In the admin panel, you set rates, change the default password and test with a ₱1 coin.
These Piso WiFi setup steps fit most Orange Pi builds running LPB or AdoPiSoft.
- Download the official firmware image from your software’s site.
- Flash the SD card with balenaEtcher and insert it into the board.
- Plug the ISP modem into the WAN port and the access point into the LAN port, using a USB-to-LAN adapter on single-port boards.
- Power on and open the admin page from a connected phone, which is 10.0.0.1/admin on LPB.
- Change the default admin password, because default logins are public.
- Set timer rates, coin denominations, pause settings and session expiry.
- Drop a ₱1 coin to test that the portal opens and time is added.
Following these steps in order is how to install piso wifi vendo machine parts without missing a setting. If you’re learning how to setup piso wifi vendo machine software, we recommend starting with an Orange Pi and LPB, since both are low-cost and widely supported.
What does a Piso WiFi wiring diagram look like?
A Piso WiFi wiring diagram shows the coin acceptor’s signal wire going to a GPIO pin on the board, with a relay controlling the coin acceptor. An HW-688 buck converter turns one 12V 5A supply into 12V for the coinslot and 5V USB power for the board.
MakerLab’s Piso WiFi Orange Pi diagram for LPB connects the parts like this.
| Wire or part | Connects to |
|---|---|
| Coin signal (white wire) | A 1N4001 diode, then pin 3 |
| Coin power (red and black wires) | The HW-688’s 12V output |
| Coinslot SET pin | The relay’s NC terminal |
| Relay IN | Pin 5 |
| Relay VCC and GND | The board’s 5V and GND pins |
| Relay COM | The HW-688’s 12V negative |
| Insert-coin LED | +12V through a 1k ohm resistor, with the short leg to the relay’s NO terminal |
| Board power | The HW-688’s USB port |
This piso wifi diagram with relay is for LPB on an Orange Pi. Other systems and custom boards can use different pins, so always follow your firmware’s own piso wifi wiring diagram.
How do you set up VLAN for Piso WiFi?
You set up VLAN for Piso WiFi by giving each access point or sub vendo its own VLAN ID, then linking them to the board through one switch. The board tells the traffic apart by that ID, so one machine can run several access points over a single cable.
For a VLAN setup, Piso WiFi owners follow four steps.
- Create a VLAN ID for each access point in your Piso WiFi software.
- Set the same VLAN ID on the matching access point.
- Connect each access point to the switch, using a managed switch if you need to assign VLANs per port.
- Connect the switch to the board’s LAN port and test each access point.
LPB includes VLAN features with an auto-select coinslot in both of its licenses. AdoPiSoft sells a DIY kit built for TP-Link EAP110 VLAN setup. A Piso WiFi VLAN setup tutorial for your own software shows exactly where these settings sit.
What can you manage after installing a Piso WiFi vendo?
After installing a Piso WiFi vendo, you can manage rates, time packages, pause rules, vouchers, speed limits, connected users and sales from the admin dashboard. LPB Lite includes one sub-account for a helper, while Premium allows unlimited sub-accounts, so a store helper can check the machine without your main login.
Per-user speed limits stop one heavy user from slowing everyone else, and a global limit protects your whole line. The voucher generator creates codes to sell at the counter, and the client list shows who is connected. On LPB, Cloud Session stores each customer’s time in the LPB Cloud, so paused time carries across machines.
How do you monitor a Piso WiFi vendo remotely?
You monitor a Piso WiFi vendo remotely through LPB’s built-in Remote Monitoring, which works from your LPB account without third-party tools like NGROK. On systems like Wifi5soft, owners use ZeroTier to reach the dashboard from anywhere. LPB’s LPBSoft App for iOS also shows whether each machine is online or offline.
The app can send commands to a machine, which saves a trip for simple fixes. ZeroTier works by putting your phone and the vendo on the same private network, so the dashboard opens as if you were on site.
How do you design a Piso WiFi tarpaulin and signage?
You design a Piso WiFi tarpaulin by putting your rates, your WiFi name (SSID) and the steps to connect on it, in letters you can read from the street. Customers should know the price and the network before they take out their phone. On TP-Link’s example rate card, ₱10 buys 2 hours and ₱20 buys 5 hours.
A clear piso wifi tarpaulin design leads with “Piso WiFi available here,” then the rate card and three short connect steps. Add your Piso WiFi logo so regulars recognize you, and use the same colors on your portal background.
Free Canva templates work for banners and stickers, and any local printer can size the tarp to your wall. Piso WiFi signage reads fastest in the words your customers use, including Taglish.
How do you maintain a Piso WiFi vending machine?
You maintain a Piso WiFi vending machine by cleaning the coin acceptor, clearing dust from the vents, and checking the cables and power supply. Back up your settings before any firmware update. On LPB, the LPBSoft App shows whether the machine is online, so you can do the daily check from your phone.
| How often | Task |
|---|---|
| Daily | Check the machine is online, test a coin and read customer complaints |
| Weekly | Empty the coin bank, wipe the coin acceptor and watch peak-hour speed |
| Monthly | Clear dust, check cables and the adapter, and back up before updates |
We recommend keeping a spare coin acceptor, a flashed SD card and a power adapter on hand. You can swap each of them in minutes, so one failed part doesn’t keep the machine offline while you wait for a delivery.
What problems do Piso WiFi vendo owners run into?
Common problems Piso WiFi vendo owners run into are coins not detected, wrong time added, restarts, slow WiFi and customers who can’t connect. Coin and timer problems trace back to the coinslot settings or wiring, while restarts and slow WiFi trace back to power or bandwidth. Each one has a quick first check.
| Problem | Check first | Next step |
|---|---|---|
| Coin not detected | The coin acceptor’s wiring | Recalibrate the coin acceptor |
| Wrong time added | Timer rates and coin settings | Re-enter rates and test each coin |
| Machine keeps restarting | The power adapter and ventilation | Replace the adapter or add a UPS |
| Slow WiFi | Number of users and speed limits | Lower per-user limits or upgrade the plan |
| Customers can’t connect | Signal coverage and the WiFi name | Move or add an access point |
| Portal won’t open | The access point’s link to the LAN port | Restart the board and access point |
| Admin page won’t open | That your device is on the vendo network | Check the gateway address |
| Session doesn’t end | Session expiry settings | Re-save expiry and reboot |
If you’re learning how to fix Piso WiFi vendo machine faults, start with these checks before calling a technician.
FAQs
Why are Piso WiFi vendo machines popular with small businesses?
Piso WiFi vendo machines are popular with small businesses because they start at about ₱6,000 and run unattended. Customers pay from ₱1, so sales add up.
How do you make Piso WiFi without a vendo machine?
You make Piso WiFi without a vendo machine by selling vouchers through the Voucher Portal on TP-Link Omada access points. Customers enter a code to connect.
How much does it cost to run a Piso WiFi vendo each month?
Running a Piso WiFi vendo each month costs internet plan plus electricity, about ₱271 for a 25 W setup. Licenses renew yearly, with no franchise fee.
How much can a Piso WiFi vendo earn?
A single Piso WiFi vendo can earn ₱6,000 to ₱15,000 a month in sales at low traffic, per TP-Link’s operator-reported estimates. Results aren’t guaranteed.
Is a Piso WiFi vendo illegal?
A Piso WiFi vendo is not illegal once registered with DTI, your barangay, the Mayor’s office and BIR. DTI registration costs under ₱1,000.
Who invented the Piso WiFi vendo in the Philippines?
No verified inventor of the Filipino Piso WiFi vendo exists. It grew from early-2010s PisoNet coin computers, and WiFi vendos were on sale by 2016.
Does every Piso WiFi vendo use 10.0.0.1?
Not every Piso WiFi vendo uses 10.0.0.1, because each software sets its own gateway address. On Windows, ipconfig shows it as the Default Gateway.
Final Thoughts
A Piso WiFi vendo machine is a low-cost small business, and its results depend more on location and internet quality than on the brand of box. TP-Link’s own guide notes that earnings vary with location, competition and ISP uptime. A DIY kit costs least, while a plug-and-play unit saves you the wiring.
In our experience, owners who do well buy from sellers who register the license in their name and mount an outdoor access point where people already wait. Coin jams and slow WiFi at night usually trace back to a cheap coin acceptor or an undersized plan. A weekly coinslot clean and a plan sized for peak hours keep both in check.
Before you buy, note where the machine will go, how many people stay there at once, and which internet line reaches it. Then ask two sellers for a written parts list and compare them line by line.
